Crawler Mounted Drill Rigs

Single Head Systems

The Comacchio GEO line of water well and geothermal drilling rigs embraces an extremely diversified selection of eleven models. It ranges from lightweight and small footprint units ideally suited for tight work sites, usually associated with residential and small-scale commercial geothermal and water well drilling projects, to heavy-duty machines with up to 50 tonnes pull up capacity, reaching over 1000 m drilling depth.

The Comacchio GEO line drill rigs are designed as multipurpose units, able to meet the different requirements and needs related to water well and geothermal drilling projects. Thanks to their flexible design, based on the use of advanced modular hydraulic circuits, these machines can adapt to all of the most commonly used drilling techniques, depending on borehole diameter, required drilling depth and soil conditions on-site, including:

rotary drilling with direct air/water/mud flushing;
reverse circulation mud drilling;
rotary-percussive drilling with down-the-hole hammer (DTH drilling).

The development of a wide range of rod handling systems has allowed mechanizing and automating, partly or completely, the handling of rods, increasing safety levels and productivity.

The range of uses of these machines include installation of piezometers and groundwater monitoring wells, construction of wells for public, agriculture, commercial, industrial and domestic water supply, installation of geothermal probes, along with well repairs and deepening.

Crawler Mounted Drill Rigs MODELS

GEO 405

GEO 405

GEO 405

EU | US

Engine Power 55 - 74 kW
Retract Force 6.500 daN
Weight 5.800 - 7.000 kg

Engine Power 74  - 99 HP
Retract Force 14,612 lbs
Weight 12,800 - 15,400 lbs

Continue

GEO 500

GEO 500

GEO 500

EU | US

Engine Power 55 kW
Retract Force 6.500 daN
Weight 7.000 - 8.500 kg

Engine Power 74 HP
Retract Force 14,612 lbs
Weight 15,400 - 18,700 lbs

Continue

GEO 501

GEO 501

GEO 501

EU | US

Engine Power 95 - 115 kW
Retract Force 6.500 daN
Weight 8.500 - 9.500 kg

Engine Power 127 - 154 HP
Retract Force 14,612 lbs
Weight 18,700 - 21,000 lbs

Continue

GEO 600

GEO 600

GEO 600

EU | US

Engine Power 55 - 74 kW
Retract Force 6.500 daN
Weight 6.500 - 8.000 kg

Engine Power 74 - 99 HP
Retract Force 14,612 lbs
Weight 14,000 - 17,500 lbs

Continue

GEO 601

GEO 601

GEO 601

EU | US

Engine Power 86 - 100 kW
Retract Force 6.500 daN
Weight 7.000 - 9.000 kg

Engine Power 115 - 134 HP
Retract Force 14,612 lbs
Weight 15,500 - 20,000 lbs

Continue

GEO 655

GEO 655

GEO 655

EU | US

Engine Power 100 kW
Retract Force 6.500 daN
Weight 11.000 - 11.500 kg

Engine Power 134 HP
Retract Force 14,612 lbs
Weight 24,000 - 25,300 lbs

Continue

GEO 602

GEO 602

GEO 602

EU | US

Engine Power 115 - 119 kW
Retract Force 9.500 daN
Weight 9.000 - 10.000 kg

Engine Power 154 - 160 HP
Retract Force 21,357 lbs
Weight 20,000 - 22,000 lbs

Continue

GEO 700 A

GEO 700 A

GEO 700 A

EU | US

Engine Power 129 kW
Retract Force 9.500 daN
Weight 12.000 - 13.000 kg

Engine Power 173 HP
Retract Force 21,357 lbs
Weight 26,500 - 28,700 lbs

Continue

GEO 900

GEO 900

GEO 900

EU | US

Engine Power 126 - 160 kW
Retract Force 15.000 / 19.500 daN
Weight 13.000 - 15.000 kg

Engine Power 169 - 214 HP
Retract Force 33,721 / 43,840 lbs
Weight 28,700 - 33,100 lbs

Continue

GEO 901

GEO 901

GEO 901

EU | US

Engine Power 188 - 225 kW
Retract Force 20.000 / 30.000 daN
Weight 19.000 - 22.000 kg

Engine Power 255 - 306 HP
Retract Force 44,961 / 67,440 lbs
Weight 42,000 - 48,500 lbs

Continue

GEO 903

GEO 903

GEO 903

EU | US

Engine Power 245 kW
Retract Force 30.000 daN
Weight 28.000 kg

Engine Power 333 HP
Retract Force 67,442 lbs
Weight 61,700 lbs

Continue

GEO 905

GEO 905

GEO 905

EU | US

Engine Power 285 kW
Retract Force 50.000 daN
Weight 35.000 kg

Engine Power 385 HP
Retract Force 112,400 lbs
Weight 77,000 lbs

Continue
