| Diesel engine | Cummins QSB6.7 (EU Stage IIIA/Stage V - US EPA Tier 3 / Tier 4f) | |
| Power rating | 201 - 231 kW/ 2000 rpm | 270 - 310 HP/2000 rpm |
| Nominal max torque | 184 kNm | 135,700 lbf*ft |
| Weight | 46000 kg | 101,400 lbs |
| CFA | ||
| Max pile diameter | 1000 mm | 3' 3" |
| Max length of augers | 21 m | 69' |
| Max length of auger extension | 6 m | 19' 8" |
| Max pile depth | 21 + 6 = 27 m | 69’ + 19‘ 8" = 89” |
| Extraction force | 540 kN | 121,400 lbs |
| Crowd force on auger (option) | 45 / 100 kN | 10,200 / 22,500 lbs |
