CARACTÉRISTIQUES TECHNIQUES

Puissance moteur diesel 33 kW ( 44 HP)
Moteur eléctrique 30 kW
Largeur max 735 - 1.000 mm 2' 5'' - 3' 3''
Poids 2,5 - 3 ton
Course du mât 1.000 - 2.250 mm 3' 3'' - 7' 5'' ft-in
Poussée 2.500 daN 5,620 lbs
Traction 2.500 daN 5,620 lbs
Couple rotary 225 - 430 daNm 1,660 - 3,172 lb*ft
Vitesse rotary 80 - 810 rpm
Tige diamètre min/max 45 - 160 mm 1'' 3/4 - 6'' 5/16 in
