Foreuses hydrauliques pour la réalisation d’ouvrages de fondations et de murs de soutènement avec la technologie CFA (Continuous Flight Auger - pieux à la tarière creuse continue).
Diamètre max. | 750 mm |
Longueur max. tarières | 8.5 m |
Longueur max. rallonge | 4.0 m |
Profondeur max. | 8.1 + 4.0 = 12.1 m |
Force d'extraction | 170 kN |
Poussée sur tarières (option) | 60 kN |
Diamètre max. | 2’ 6” |
Longueur max. tarières | 27’ 11” |
Longueur max. rallonge | 13’ 1” |
Profondeur max. | 26’ 7” + 13’ 1” = 39’ 8” |
Force d'extraction | 37,217 lbs |
Poussée sur tarières (option) | 13,500 lbs |
Diamètre max. | 800 mm |
Longueur max. tarières | 13.5 m |
Longueur max. rallonge | 6.0 m |
Profondeur max. | 13 + 6.0 = 19 m |
Force d'extraction | 320 kN |
Poussée sur tarières (option) | 45 kN |
Diamètre max. | 2’ 7” |
Longueur max. tarières | 44’ 4” |
Longueur max. rallonge | 19’ 8” |
Profondeur max. | 42’ 8” + 19’ 8” = 62’ 4” |
Force d'extraction | 71,900 lbs |
Poussée sur tarières (option) | 10,100 lbs |
Diamètre max. | 800 mm |
Longueur max. tarières | 14.5 m |
Longueur max. rallonge | 6.0 m |
Profondeur max. | 14 + 6.0 = 20 m |
Force d'extraction | 320 kN |
Poussée sur tarières (option) | 45 kN |
Diamètre max. | 2’ 7” |
Longueur max. tarières | 47’ 6” |
Longueur max. rallonge | 19’ 8” |
Profondeur max. | 45’ 11” + 19’ 8” = 65’ 7” |
Force d'extraction | 71,900 lbs |
Poussée sur tarières (option) | 10,100 lbs |
Diamètre max. | 800 mm |
Longueur max. tarières | 12.5 m |
Longueur max. rallonge | 7 m |
Profondeur max. | 11 + 7 = 18 m |
Force d'extraction | 250 kN |
Poussée sur tarières (option) | 100 kN |
Diamètre max. | 2’ 7” |
Longueur max. tarières | 41’ |
Longueur max. rallonge | 23’ |
Profondeur max. | 36’ 1" + 23’ = 59’ 1" |
Force d'extraction | 56,200 lbs |
Poussée sur tarières (option) | 22,500 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 17 m |
Longueur max. rallonge | 6.0 m |
Profondeur max. | 16.5 + 6.0 = 22.5 m |
Force d'extraction | 480 kN |
Poussée sur tarières (option) | 100 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 55' 9" |
Longueur max. rallonge | 19’ 8” |
Profondeur max. | 54’ 2” + 19’ 8” = 73’ 10” |
Force d'extraction | 107,900 lbs |
Poussée sur tarières (option) | 22,500 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 18.5 m |
Longueur max. rallonge | 6.0 m |
Profondeur max. | 18 + 6.0 = 24 m |
Force d'extraction | 480 kN |
Poussée sur tarières (option) | 100 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 60' 8" |
Longueur max. rallonge | 19’ 8” |
Profondeur max. | 59’ 1” + 19’ 8” = 78’ 9” |
Force d'extraction | 107,900 lbs |
Poussée sur tarières (option) | 22,500 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 19.5 m |
Longueur max. rallonge | 6.0 m |
Profondeur max. | 19 + 6.0 = 25 m |
Force d'extraction | 480 kN |
Poussée sur tarières (option) | 100 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 63' 11" |
Longueur max. rallonge | 19’ 8” |
Profondeur max. | 62’ 4” + 19’ 8” = 82’ |
Force d'extraction | 107,900 lbs |
Poussée sur tarières (option) | 22,500 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 16 m |
Longueur max. rallonge | 7 m |
Profondeur max. | 14 + 7 = 21 m |
Force d'extraction | 330 kN |
Poussée sur tarières | 140 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 52’ 6” |
Longueur max. rallonge | 23’ |
Profondeur max. | 46’ + 23’ = 69’ |
Force d'extraction | 74,200 lbs |
Poussée sur tarières | 31,470 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 21 m |
Longueur max. rallonge | 6 m |
Profondeur max. | 21 + 6 = 27 m |
Force d'extraction | 540 kN |
Poussée sur tarières | 45 / 100 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 69' |
Longueur max. rallonge | 19’ 8'' |
Profondeur max. | 69’ + 19’ 8'' = 89' |
Force d'extraction | 121,396 lbs |
Poussée sur tarières | 10,200 / 22,500 lbs |
Diamètre max. | 1000 mm |
Longueur max. tarières | 17.5 m |
Longueur max. rallonge | 7 m |
Profondeur max. | 15.5 + 7 = 22.5 m |
Force d'extraction | 580 / 700 kN |
Poussée sur tarières | 140 kN |
Diamètre max. | 3’ 3” |
Longueur max. tarières | 57’ 5” |
Longueur max. rallonge | 23’ |
Profondeur max. | 50’ 10" + 23’ = 73’ 10" |
Force d'extraction | 130,400 / 157,400 lbs |
Poussée sur tarières | 31,500 lbs |
Diamètre max. | 1200 mm |
Longueur max. tarières | 27 m |
Longueur max. rallonge | 6 m |
Profondeur max. | 26.5 + 6 = 32.5 m |
Force d'extraction | 1120 kN |
Poussée sur tarières | 150 kN |
Diamètre max. | 3’ 11” |
Longueur max. tarières | 88' 7" |
Longueur max. rallonge | 19’ 8'' |
Profondeur max. | 87’ + 19’ 8'' = 106' 8" |
Force d'extraction | 251,800 lbs |
Poussée sur tarières | 33,700 lbs |
