Fully Articulated Multipurpose Rigs

Microdrilling

The hallmark of our drilling rigs is the great variety of mast positions and inclinations that they are capable to perform thanks to the Comacchio patented articulation system. This unique kinematics concept was introduced for the first time by Comacchio in 1998. It has been perfected over the years to give life to the current articulation system, which allows a 180 ° rotation of the mast without re-pinning of the cylinders. The result is the great versatility in the use of these drilling rigs: our fully articulated rigs cover the entire spectrum of geotechnical engineering applications (micropiles, anchors, tie rods, soil nails, jet grouting) and are capable of operating in the most challenging jobsite conditions. Our offering ranges from compact units weighing just over 3 tonnes, designed for operation in low headroom and restricted access sites, to large drilling rigs weighing up to 30 tonnes and providing over 200 kW of power, designed for the most demanding jobs and heavy duty drilling methodologies, including double head applications. With a view to improving productivity and safety levels, the Comacchio MC line rigs can be offered with an array of automated rods and casings handling solutions.

Fully Articulated Multipurpose Rigs MODELS

MC 2

MC 2

MC 2

EU | US

Engine Power 33 kW
Retract Force 2.500 daN
Weight 2.500 - 3.000 kg

Engine Power 44 HP
Retract Force 5,620 lbs
Weight 5,510 - 6,615 lbs

Continue

MC 3

MC 3

MC 3

EU | US

Engine Power 55 kW
Retract Force 2.500 daN
Weight 3.500 - 4.000 kg

Engine Power 74 HP
Retract Force 5,620 lbs
Weight 7,700 - 8,800 lbs

Continue

MC 6

MC 6

MC 6

EU | US

Engine Power 93 - 100 kW
Retract Force 5.000 daN
Weight 6 - 7,5 ton

Engine Power 125 - 134 HP
Retract Force 11,240 lbs
Weight 6 - 7,5 ton

Continue

MC 6S

MC 6S

MC 6S

EU | US

Engine Power 100 kW
Retract Force 5.000 daN
Weight 6,5 - 7,5 ton

Engine Power 134 HP
Retract Force 11,240 lbs
Weight 6,5 - 7,5 ton

Continue

MC 8

MC 8

MC 8

EU | US

Engine Power 86 - 100 kW
Retract Force 5.000 daN
Weight 8 - 9 ton

Engine Power 115 - 134 HP
Retract Force 11,240 lbs
Weight 8 - 9 ton

Continue

MC 12

MC 12

MC 12

EU | US

Engine Power 95 - 115 kW
Retract Force 5.400 daN
Weight 11,5 - 13,5 ton

Engine Power 127 - 154 HP
Retract Force 12,139 lbs
Weight 11,5 - 13,5 ton

Continue

MC 12 P

MC 12 P

MC 12 P

EU | US

Engine Power 140 kW
Retract Force 5.400 daN
Weight 13 - 15 ton

Engine Power 188 HP
Retract Force 12,139 lbs
Weight 13 - 15 ton

Continue

MC 14

MC 14

MC 14

EU | US

Engine Power 140 kW
Retract Force 5.400 daN
Weight 14 - 15 ton

Engine Power 188 HP
Retract Force 12,140 lbs
Weight 14 - 15 ton

Continue

MC 15

MC 15

MC 15

EU | US

Engine Power 119 - 140 kW
Retract Force 8.000 daN
Weight 14,5 - 16,5 ton

Engine Power 160 - 188 HP
Retract Force 17,985 lbs
Weight 14,5 - 16,5 ton

Continue

MC 15 P

MC 15 P

MC 15 P

EU | US

Engine Power 168 kW
Retract Force 8.000 daN
Weight 16.500 - 18.500 kg

Engine Power 225 HP
Retract Force 17,984 lbs
Weight 36,400 - 40,700 lbs

Continue

MC 20

MC 20

MC 20

EU | US

Engine Power 209 kW
Retract Force 10.000 daN
Weight 19.500 - 21.500 kg

Engine Power 280 HP
Retract Force 22,480 lbs
Weight 42,900 - 47,400 lbs

Continue

MC 20 A

MC 20 A

MC 20 A

EU | US

Engine Power 209 kW
Retract Force 10.000 daN
Weight 20.500 - 22.000 kg

Engine Power 280 HP
Retract Force 22,480 lbs
Weight 45,200 - 48,500 lbs

Continue

MC 22 A

MC 22 A

MC 22 A

EU | US

Engine Power 180 - 205 kW
Retract Force 9.500 daN
Weight 24 -25 ton

Engine Power 240 - 278 HP
Retract Force 21,360 lbs
Weight 24 - 25 ton

Continue

MC 22

MC 22

MC 22

EU | US

Engine Power 180 - 205 kW
Retract Force 9.500 daN
Weight 22 - 24 ton


Engine Power 240 - 278 HP
Retract Force 21,356 lbs
Weight 22 - 24 ton

Continue

MC 28

MC 28

MC 28

EU | US

Engine Power 188 - 245 kW
Retract Force 9.500 - 14.000 daN
Weight 26 - 28 ton

Engine Power 252 - 333 HP
Retract Force 21,357 - 31,473 lbs
Weight 26 - 28 ton

Continue

MC 28 HD

MC 28 HD

MC 28 HD

EU | US

Engine Power  225 kW
Retract Force 14.000 daN
Weight 29 - 30 ton

Engine Power 302 HP
Retract Force 31,473 lbs
Weight 29 - 30 ton

Continue

MC 28 A HD

MC 28 A HD

MC 28 A HD

EU | US

Engine Power 225 kW
Retract Force 9.500 daN
Weight 29 - 31 ton

Engine Power 302 HP
Retract Force 21,357  lbs
Weight 29 - 31 ton

Continue
