TECH DATA

Engine Power 55 kW ( 74 HP)
Max Width 900 - 1.350 mm 2.9 - 4.4 ft
Weight 3.500 - 4.000 kg 7,700 - 8,800 lbs
Mast Force 1.200 - 2.200 mm 3.9 - 7.2 ft
Feed Force 2.500 daN 5,620 lbs
Retract Force 2.500 daN 5,620 lbs
Rotary Torque 200 - 510 daNm 1,475 - 3,761 lb*ft
Rotary Speed Range 80 - 560 rpm
Clamp Range 45 - 260 mm 1.8 - 10.2 in
